Big Tex Heavy Duty Low Profile Dump Trailer | 14XD-14C2A
$1,424.85
14EH Equipment Trailer
Description
Part of the all-new X-Series, the 14EH Equipment Trailer from Big Tex Trailers is engineered for professionals who demand durability and innovation. The 14EH features APEX Fortified Lumber for superior deck durability and a Mega-Sized Toolbox for added storage capacity. It’s enhanced with a Full-Length Rub Rail, D-Rings, and Stake Pockets, providing multiple secure tie-down options for a variety of cargo. The 14EH revolutionizes loading and unloading with its optional Self-Stabilizing Mega Ramps, offering unparalleled flexibility for all your hauling needs.
Standard Features
- 2 – 7,000# Premium Cambered Axles with Quick-Lubricating Hubs
- Forward Self-Adjusting Electric Brakes on All Hubs
- Multi-Leaf Slipper Spring Suspension with Equalizer
- Adjustable 2-5/16” Demco EZ Latch Coupler
- 12,000# Drop-Leg Jack (Side Wind)
- 8″ I-Beam Frame
- 3″ Channel Cross-Members on 16″ Centers
- 3/16″ Fabricated Front Stop Rail
- APEX Fortified Lumber Floor
- 5′ Tall Stand-Up Ramps (Spring Assisted)
- 40” Cleated Dovetail
- Stake Pockets Along Both Sides
- 7-Way RV Trailer Plug
- LED DOT Stop, Tail, Turn & Clearance Lights
- Sealed Modular Cold-Weather Wiring Harness
- ST235/80 R-16 Load Range E Radial Tires
- Rub Rail Along Both Sides
- (6) 5/8″ D-Rings
- Complete Breakaway System
- Mega-Sized Integrated Tongue Box with Lockable Lid
- Convenient Side-Step Access
Available Options
- Adjustable Pintle Coupler
- Adjustable Gooseneck Coupler
- 36″ Wide Mega Ramps (D3 Models Only)
- Super-Wide Ramps with Blackwood Pro-Filled Dovetail
- Tire Upgrade (Load Range G)
- Spare Tire & Wheel
- Additional Paint Colors
- Lockable Toolbox on Gooseneck Models
Available Models & Specifications
| Model | Pull Type | GVWR | GAWR | Empty Weight | Cargo Capacity | Bed Length | Bed Width |
|---|---|---|---|---|---|---|---|
| 14EH-16D3A | Bumperpull | 15,400 lbs | 7,000 lbs | 2,860 lbs | 12,540 lbs | 16′ | 83″ |
| 14EH-18D3A | Bumperpull | 15,400 lbs | 7,000 lbs | 3,020 lbs | 12,380 lbs | 18′ | 83″ |
| 14EH-20D3A | Bumperpull | 15,400 lbs | 7,000 lbs | 3,150 lbs | 12,250 lbs | 20′ | 83″ |
| 14EH-22D3A | Bumperpull | 15,400 lbs | 7,000 lbs | 3,330 lbs | 12,070 lbs | 22′ | 83″ |
| 14EHG-20D3A | Gooseneck | 15,900 lbs | 7,000 lbs | 3,740 lbs | 12,160 lbs | 20′ | 83″ |
| 14EHG-22D3A | Gooseneck | 15,900 lbs | 7,000 lbs | 3,940 lbs | 11,960 lbs | 22′ | 83″ |
| 14EHG-24D3A | Gooseneck | 15,900 lbs | 7,000 lbs | 4,140 lbs | 11,760 lbs | 24′ | 83″ |
